Radium Clutch Fork Stop - Mitsubishi Evo 8-X

Radium Clutch Fork Stop - Mitsubishi Evo 8-X

Application: Mitsubishi Lancer Evolution 7, 8, 9 and 10 (manual) and Galant EC5
Part Type: Clutch fork stop
Part Number: 20-0262

The Radium Clutch Fork Stop solves a known issue with the Mitsubishi Evo pull-type clutch slave cylinder. Under hard shifting or fast clutch pedal use, the clutch fork can over-return and unclip the throw-out bearing – a failure that can mean removing the transmission to fix.

The stop prevents the fork over-travelling. It is multi-axis CNC machined so the hex adjustment bolt sits precisely square to the clutch fork.

Key Features

• Prevents Over-Return: Stops the clutch fork over-travelling and unclipping the throw-out bearing
• Precision Machined: Multi-axis CNC machining positions the adjustment bolt square to the fork
• Adjustable: Stainless steel adjustment screw with lock nut
• Anodised Finish: CNC machined and anodised
• Stainless Hardware: Stainless steel mounting bolts included

What's Included

• CNC machined, anodised clutch fork stop
• Stainless steel adjustment screw and lock nut
• Stainless steel mounting bolts

Important Notes

• Suits manual transmissions only – Evo X fitment is the 5-speed manual
• Installation instructions are available in the Instructions tab

Vehicle Fitment

• Mitsubishi Lancer Evolution VII – 5-speed manual
• Mitsubishi Lancer Evolution VIII – 5-speed and 6-speed manual
• Mitsubishi Lancer Evolution IX – 5-speed and 6-speed manual
• Mitsubishi Lancer Evolution X – 5-speed manual
• Mitsubishi Galant EC5 – 5-speed manual

Not sure if this suits your vehicle? Email sales@coore.com.au and our team will confirm fitment.
